Guangzhou Aozoom Auto Lighting Co., Ltd. is one of the leading manufacturers and suppliers of led dual lens grille light in China. If you're going to wholesale advanced led dual lens grille light made in China, welcome to get quotation from our factory. All customized products are with high quality and competitive price.
Multi-Lens High-Density LED Array
The LED Dual Lens Grille Light W7 employs two optical chambers, each containing six low-beam and six high-beam LEDs, creating a dense, overlapping light pattern that eliminates shadows and maximizes coverage. The dual-lens design allows separate optimization for width and distance.
- Low beam: Big-wafer 6-core lamp beads ×2 + super-wide tri-cell beads ×2
- High beam: Enhanced 3-core lamp beads ×2 for extreme long-range output
- Hyperbolic focusing optics for sharp cutoff and minimal scatter
Intelligent Thermal & Power Design
A multi-fan active cooling system paired with heat pipes and a temperature-control IC ensures the high-power LEDs remain stable. The power supply includes over-voltage, over-current, and reverse-polarity protection for vehicle electrical safety.
- Maintains performance in ambient temperatures from -40°C to +105°C
- Consistent brightness without fade over extended use
- 25,000-hour rated lifespan under normal conditions
Ruggedized Housing & Environmental Sealing
The housing of LED Dual Lens Grille Light W7 is constructed from die-cast aluminum with a fully sealed lens assembly rated IP67. It withstands vibration, moisture, dust, and chemical exposure, making it suitable for the toughest environments.
- High-temperature silicone gaskets and stainless steel hardware
- Scratch-resistant coated polycarbonate lens
- Corrosion-protected surface finish
PRODUCT PARAMETERS
PRODUCT SPECIFICATION
|
Input Power |
L/60W ±2W; H/108W ±2W |
|
Light Source Model |
L/6 CORE*2 55*55MIL + 3 CORE*2 60*68MIL+H/3 CORE*2 60*68 MIL |
|
Color Temperature |
6000K |
|
Voltage Range |
9V–16V DC |
|
Theoretical Lifespan |
25,000 hours |
|
Operating Temperature |
-40℃ to +105℃ |
|
Protection Rating |
IP67 |
Quality Control & Certifications
100% performance validation and burn-in testing
Certifications: CE, RoHS, IP67, E-mark (on request)
Quality management system ISO 9001 compliant
OEM/ODM Customization
Full OEM/ODM support including optical design, power customization, branding, packaging, and compliance tailoring for international markets.
After-Sales Service
2-year warranty for commercial users
Priority technical support and field service guidance
Global spare parts network
HIGH LUMINOUS EFFICIENCY
2*6+2*3+2*3 LAMP BEADSCHEME
LOW BEAM PAVING IS THICK AND UNIFORM, HIGH BEAM IS FOCUSED AND NOT GLARING
APPLICATIONS
Extreme off-road and rally racing
Military, emergency, and security vehicle lighting
Mining, forestry, and heavy machinery
Marine and aviation ground support lighting
FAQ
Q: What is the recommended power supply setup for the W7?
A: A direct battery connection with an appropriate fuse and relay is recommended for optimal performance.
Q: Can the W7 be used in combination with a light bar?
A: Yes, it can be paired with light bars for full 360° auxiliary lighting setups.
Q: Is dimming or strobe function available?
A: Custom control options are available for special orders (e.g., dimming, strobe, wireless control).
CONTACT US
For pricing or technical support, please contact us via email at aozoom@163.com or call customer service at 400-1020-039.
